Usage: Forming trapezoidal metal roofing sheets
Raw Material: Galvanized steel, PPGI, aluminum coil
Sheet Thickness: 0.3–0.8 mm
Coil Width: 914 mm to 1250 mm
Line Speed: 10–18 m/min
Roller Stations: 16–22 steps
Rollers: 45# steel, hard chrome-plated
Cutting Type: Hydraulic post-cutting
Blade Material: Cr12 with heat treatment
Controller: Siemens/Mitsubishi PLC system
Screen: 7-inch touch screen with HMI
Transmission: Chain or gear drive
Main Motor: 5.5–11 kW depending on configuration
Hydraulic Unit: 4 kW pump station
Power Supply: 380V/50Hz/3Phase (customizable)
Machine Size: About 9m x 1.5m x 1.5m
Weight: 7 tons approx.
Output System: Integrated automatic output table
Cutting Accuracy: ±1 mm
Noise Level: ≤75 dB
Application: Roofing, siding, facade panels
Material Handling: Manual or hydraulic decoiler (optional)
Operation: Fully automatic production line
Safety: Equipped with emergency stop and protective covers
Surface Finish: Painted, corrosion-resistant
Maintenance: Easy-to-maintain design
Customization: Profile and color can be tailored
Working Environment: Designed for industrial use
Certifications: CE, ISO9001
Installation: On-site or remote support available
After-Sales: 12-month warranty, lifetime tech support
Machine Type: Cold roll forming
Brand: TOPPO Machinery
Features: Energy-efficient, robust structure, long lifespan
Industry: Construction, metal building, prefab housing
Line Components: Decoiler – Roll Forming – Cutting – Output
This PLC-controlled trapezoidal roll forming machine is ideal for customers looking for a fully automated solution to produce metal roofing panels with precision and consistency. The system integrates an output table for enhanced productivity.
