This aluminum steel roofing sheet roll forming machine is designed for high-speed, continuous production of roofing panels with excellent precision and durability. It is widely used in construction and industrial manufacturing for producing corrugated and trapezoidal metal sheets.
Material: Aluminum, Galvanized Steel, Color Coated Steel
Forming Technology: Cold Roll Forming
Frame Structure: Heavy-duty welded steel frame
Control System: PLC fully automatic control
Operation Panel: Touch screen HMI system
Cutting System: Hydraulic automatic cutting device
Cutting Precision: ±1mm tolerance
Forming Speed: 10-18 m/min
Roller Stations: 14-20 stations
Roller Material: High-quality 45# steel
Roller Treatment: Hard chrome plating
Shaft Material: High-strength steel
Shaft Diameter: 70-90mm
Transmission: Chain drive or gearbox optional
Main Motor Power: 5.5-15KW
Hydraulic Power: 3-5.5KW
Voltage: 380V/50Hz/3Phase (customizable)
Sheet Thickness Range: 0.3-0.8mm
Feeding Width: Customizable
Effective Width: Based on design
Profile Type: Corrugated / Trapezoidal
Production Mode: Continuous automatic forming
Noise Level: Low noise
Lubrication: Automatic lubrication system
Cooling System: Built-in cooling structure
Surface Coating: Anti-rust paint
Machine Color: Customizable
Electrical Parts: Schneider/Siemens optional
Safety Feature: Emergency stop system
Automation Level: Fully automatic
Operation: Simple and user-friendly
Maintenance: Easy maintenance
Durability: Long service life
Installation: Overseas engineer support
Packaging: Standard export packing
Shipping: Container loading
Certification: CE, ISO
Application: Roofing sheet manufacturing
Industry: Construction, factory buildings, warehouses
Customization: Supported
The machine offers high efficiency, stable performance, and precise forming results. It helps manufacturers improve production capacity while reducing labor costs.
With robust construction and advanced control systems, it ensures long-term reliable operation and consistent product quality. It is an ideal solution for modern roofing sheet production lines.
