Material: Galvanized steel, color steel, aluminum
Material Thickness: 0.3 – 0.8 mm
Forming Speed: 10 – 15 m/min
Roller Stations: 16–24 steps
Main Frame: 350 H-beam welded
Roller Material: 45# steel, chrome coated
Cutting Type: Hydraulic post-cutting
Control System: PLC with touch screen (Siemens/Delta)
Drive Type: Chain drive / gearbox drive
Cutting Blade: Cr12MoV, heat-treated
Voltage: 380V/50Hz/3Phase (customizable)
Power: 5.5–11 KW main motor
Hydraulic Station Power: 4 KW
Weight: 6.5 – 9 tons
Dimension: Approx. 8.5 x 1.6 x 1.5 m
Output Length Tolerance: ±1.5 mm
Automatic Material Feeding
Profile Customization Available
Noise Level: ≤75 dB
Easy Maintenance Design
Manual Decoiler or Hydraulic Decoiler Optional
Safety Covers Included
Operational Language: Multi-language support
Application: Roofing systems, industrial warehouses, factories, etc.
Installation Support: On-site or remote
Certification: CE, ISO9001
Warranty: 12 – 24 months
Training: Provided with manual and video
Roller Shaft Diameter: 70 – 90 mm
Roll Forming Tolerance: ≤±1 mm
Roller Forming Direction: Left to right
Hydraulic Oil: 46# anti-wear hydraulic oil
Cooling System: Optional (for tropical climates)
Color: Custom paint options available
Panel Width Range: 600 – 1250 mm
Feeding Material Width: As per profile drawing
Roller Layout: Horizontal aligned
Profile Drawing Support: Included with order
Packaging: Standard export packing
Delivery Time: 30 – 45 days
