Product Overview

This AG roofing panel roll forming machine is a fully automated production line engineered for manufacturing high-quality metal roofing sheets. With a robust structure, advanced PLC control system, and precision rollers, it ensures stable operation, high efficiency, and consistent product quality.

Key Features & Technical Specifications

• Machine Type: AG roofing panel roll forming machine

• Forming Process: Continuous cold roll forming

• Automation Level: Fully automatic

• Control System: PLC control with touch screen interface

• Material Compatibility: PPGI, GI, aluminum, color-coated steel

• Material Thickness: 0.3mm - 0.8mm

• Forming Speed: 10-30 m/min

• Roller Stations: 14-20 stations

• Roller Material: High-grade 45# steel

• Roller Surface Treatment: Chrome plated

• Shaft Material: Heat-treated 45# steel

• Cutting Method: Hydraulic cutting system

• Blade Material: Cr12Mov steel

• Drive System: Chain drive or gearbox optional

• Main Motor Power: 5.5KW - 11KW

• Hydraulic Power: 3KW - 5.5KW

• Voltage: 380V / 50Hz / 3 Phase (customizable)

• Feeding Width: Adjustable

• Effective Width: Based on profile design

• Frame Structure: Heavy-duty welded steel frame

• Machine Color: Customizable

• Decoiler Type: Manual or hydraulic decoiler

• Decoiler Capacity: 5T - 10T

• Leveling Device: Included

• Transmission Precision: High precision

• Length Control: Encoder controlled

• Cut Length Accuracy: ±1mm

• Electrical Components: Schneider / Delta brands

• Touch Screen Brand: Siemens / Delta optional

• Operation Language: Multi-language support

• Lubrication System: Automatic lubrication

• Cooling System: Optional configuration

• Safety Features: Emergency stop and protective covers

• Noise Level: Low noise operation

• Maintenance: Easy maintenance design

• Installation: Quick and simple setup

• Operator Requirement: Minimal labor required

• Durability: Long service life

• Production Efficiency: High output capacity

• Customization: OEM & ODM supported

• Certification: CE / ISO standards

Applications

Widely used for producing AG type metal roofing panels for factories, warehouses, workshops, agricultural buildings, logistics centers, and commercial construction projects.

Additional Advantages

This machine offers stable performance, high forming accuracy, and excellent efficiency, helping reduce labor costs and improve production consistency. It supports customized profile designs to meet diverse market demands.

We provide full technical support including installation, commissioning, training, and after-sales service to ensure long-term reliable operation.
