Material: Galvanized steel, color-coated steel, aluminum
Thickness Range: 0.3 – 0.8 mm
Forming Speed: 10 – 20 m/min
Main Power: 7.5 KW
Hydraulic Station Power: 4 KW
Control System: Delta PLC with 7" Touchscreen Interface
Cutting Method: Hydraulic post-cutting
Roller Stations: 18–22
Roller Material: 45# steel with hard chrome coating
Shaft Diameter: 70–90 mm
Base Frame: 350 H-beam welded structure
Drive Type: Gearbox drive system
Panel Width Range: 600–1250 mm
Effective Width: Based on profile design
Feeding Width: As per customer profile
Production Accuracy: ±1 mm
Decoiler: Manual or hydraulic (optional)
Safety: Protective guard, emergency stop
Noise Level: ≤70 dB
Cooling: Optional air/oil cooling system
Electrical Voltage: 380V/50Hz/3Phase or customized
Language Support: Multi-language operation interface
Installation Support: On-site or online guidance
Warranty: 1 year warranty with lifetime support
Packaging: Plastic film & steel wire fix for container loading
Delivery Time: 30–40 days after deposit
Applicable Industries: Construction, steel structure projects, prefabricated buildings
Certification: CE, ISO9001
Surface Treatment: Anti-rust coated parts
Training: Detailed manual and training video provided
Remote Assistance: Available via video call
Durability: Long-life rollers and high-precision cutters
Maintenance: Low maintenance design
