Model: TR5/TR6
Material Thickness: 0.3 – 0.8mm
Material Type: Galvanized steel, Color steel, Aluminum
Feeding Width: 914mm–1250mm (customizable)
Effective Width: Depends on final profile
Roll Stations: 16–24
Roller Material: 45# steel with hard chrome plating
Shaft Diameter: 70mm
Drive Type: Chain drive / Gear drive
Motor Power: 5.5–7.5kW
Hydraulic Power: 4kW
Control System: PLC with touch screen (Siemens/Delta)
Cutting Type: Hydraulic cutting
Cutting Blade Material: Cr12 with heat treatment
Forming Speed: 10–15m/min (excluding cutting)
Operation Mode: Automatic / Manual
Power Supply: 380V/50Hz/3Phase (customizable)
Machine Frame: 350H steel welded
Chain Size: 1.2 inch / 1.5 inch
Roller Coating: Hard chrome coating
Machine Color: Customizable (Default: Green & Blue)
Warranty: 1 year
Certification: CE certified
Application: Metal roof panel production
Production Use: Construction and Roofing Industry
Automation: Fully automatic
Worker Needed: 1–2
Installation Service: Available
After-sales Support: Online support, spare parts
Delivery Time: 30 days after deposit
Packing: Plastic film or wood case
Shipping: By sea
Maintenance: Easy to maintain
Noise Level: Low
Durability: High-strength materials
Machine Weight: About 5–8 tons
Dimension: Approx. 8.5m × 1.5m × 1.6m
Customization: Profile & voltage customizable
Usage: Long-span industrial and commercial roofs
